Amana Tool

Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop

Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop

SKU: SKU:55293

Amana Tool Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop 3/8 Dia x 7/64 Drill Dia x 1/4 Inch Quick Release Hex Shank SKU: 55293 (a°) Angle...
Full description below
Regular price $47.00
Regular price Sale price $47.00
Sale Sold out New

Order today only 1 left

This is your custom message.
View full details

Amana Tool Carbide Tipped 82 Degree Countersink with Adjustable Low Friction Depth Stop

3/8 Dia x 7/64 Drill Dia x 1/4 Inch Quick Release Hex Shank

SKU: 55293

(a°) Angle 49°
(B) Cutting Height: 5/64-11/32"
(D) Diameter: 3/8"
(d) Shank: 1/4"
(L) Overall Length: 2-3/8"
Wood Screw Size: 8
D1 7/64"
Replacement Drill: 630-224
product image

A must-have tool for every woodworker!

These tools combine carbide countersink, high-speed-steel drill bit and free-spinning, low friction depth-stop. The countersink leaves a clean hole edge and the adjustable depth-stop doesn’t mar the surface. The large openings around the collar allow the chips to clear effectively and eliminate clogging.

Enables users to drill a pilot hole and tapered countersink in one step.

The adjustable depth-stop and independent stop collar prevent marking of the workpiece and perfect countersink depth control.

  • A must-have tool for every woodworker
  • Quick-release 1/4" hex shank
  • Slow spiral, HSS M2 fully ground drill bit included

Excellent for Drilling:

  • Natural Woods
  • Man-Made Boards
  • MDF
  • Chipboard
  • Plywood
  • Aluminum/Non-Ferrous
  • Aluminum Composite Material (ACM)
  • Composites
  • Composite Decking Materials
  • Acrylic
  • High Density Polyethylene (HDPE)

Warning: When drilling aluminum/non-ferrous materials, for optimal results and extended tool life use lubricant or air cooling. Make sure the material is fixed and drill is stable during drilling.
