Felder G383 Edgebander

Felder's G383 edgebander features an advanced, user-friendly touchscreen, versatile tooling, true corner rounding capabilities, as well as pre-milling and many more options. Edge thickness is 0.4-3mm, and workpiece height is 10-50mm. The space-saving, complete finishing machine boosts production while lowering your costs, making it a perfect choice for any growing shop. 3 x 230v 3-phase and CSA approved.

Changeable Gluepot
The tool-free quick-change system of the glue pot guarantees the shortest cleaning and changeover times when changing glue or colours. The synchronized, fine-adjustable glue roller ensures the right application amount of glue. The changeable glue pot is also ideal for the processing of PUR glue.

Edge feed for panel material 10 to 50 mm thickness
Depending on the application, continuous edging film from 0.4 mm to 3.0 mm can be glued to panel materials up to 50 mm in thickness.

7” Touchscreen control
The individual machine aggregates can be switched on and off from a clearly laid out touch screen display. These include, Glue temp setting, Operating and standby temp, Engaging and disengaging of aggregates, Odometer for amount of material used, Display of the maintenance intervals, Plain text error messages.

Premilling unit ensures a perfect “finish”
Two counter-rotating, activation-controlled and individually adjustable premilling units with diamond-coated spiral cutters ensure first class edge processing before the material is glued to the edge. With the premilling unit you will achieve tear-free edges when processing laminated material. After entering the exact dimensions, the premilling unit executes a perfect edge cut on your panels.

Gluepot - short warm-up time, quick operational readiness
The Teflon-coated gluepot for PUR or EVA glue has a 1.2 kg capacity, and around 300 metres of edge material can be applied to a 19 mm panel. The short warm-up time of only 10 minutes guarantees quick operational readiness.

Pressure zone – Practically invisible glue joint
A teflon-coated aluminum roller at 90° and a rubber contact roller form the contact zone. Depending on the edge material, the contact pressure can be adjusted manually by inserting the edge material.

End trimming unit
The end trimming unit consists of a high precision linear guide that ensures perfect cuts. The saw blades rotate at 9000 rpm, guaranteeing perfect cutting results of the highest grade, regardless of edging type or wood thickness.

Multi-functional trimming unit
The biggest advantage of the combination unit is the considerably short machine length. Adjusting the settings from flush to bevelled finish for thin edges and also for radius trimming is easy and quick. 2 mm radius tooling is standard.

Radius scraping unit
The radius surface receives a light scraping, removing any remnants from the trimming process and ensuring a smooth “finish”. The fine adjustment is manual.

Buffing unit
The unit is made up of two independent electric motors, which are equipped with cotton brushes. The task of the buffing unit is to clean and polish the top and bottom part of the edge. The buffing unit gives a super finish for ABS and PVC edging material. The machine can, on request, be equipped with spraying equipment to apply polish onto the workpiece.

Spraying equipment for the perfect “finish”, leaving a workpiece requiring no further processing
Low consumption guaranteed due to application controlled spray nozzles to apply separation solution for PUR glue, antistatic solution and lubricant for sensitive edging materials and cleaning agents and polish for clean workpieces and a perfect “finish”.
